Slicer HSA-22

Fully-automatic Band Slicer with continuously rotating band blades, angled to pull the loaves through the blade almost without force to give the highest quality slice.

tin baked bread and round bread
not suitable for wet loaves or with ingredients
like raisins or fruit

length : 200 – 360 mm
width : 80 – 200 mm
height : 70 – 160 mm

standard is the slice thickness not adjustable,
but each slice thickness from 9 mm is
deliverable

55 – 60 sliced loaves per minute, depending on
the products, requirements and the operators
working on the machine

electrical connection 400 Volt – 50 Hz
power input ca. 4 kW

Top belt

Top belt to control free baked and round bread

Modular outfeed belt

Outfeed modular conveyor belt for round or oval shape bread to transport to the bagblowers

Features

Special hardened drums and blade guides for uniform slice thicknes. The various covers and doors that can be opened make the machine easy to clean.
The crumbs created during cutting are collected in the crumb tray under the outfeed table.
Infeed of the products with modular infeed belt and side belts,these side belts are adjustable by a handwheel. The infeed belt iseasy to clean and can’t be replaced by shackle instead of replacing the whole belt.
Standard with an outfeed plate and side guides to feed the sliced loaves to the packing line, controlled at the end with photocell.

Optional features

Top belt to control free baked and round bread.
Oil spray system for products with high rye content.
Hone installation to re-sharpen the band blades.
Synchronisation system for a fully automatic line.
Wide version available for products up to 460 mm in length.
Outfeed modular conveyor belt for round or oval shape bread to transport to the bagblowers.
Splitter for half of bread.
Automatic adjustable slice thickness system with touch screen 11 to 16 mm standard.
