Slicer HSB-55
Fully automatic frame slicer for many types of bread. With the trusted principle of vertical moving knives makes it ideal for products such as rye or fruit bread or different types of cake.
tin baked bread and round bread
suitable for wet loaves or with ingredients like raisins or fruit
length 200 – 360 mm
width 80 – 200 mm
height 70 – 160 mm
standard is the slice thickness not adjustable,
but each slice thickness from 9 mm is
deliverable
30 sliced loaves per minute, depending on the products, requirements and the operators working on the machine
electrical connection 400 Volt – 50 Hz
power input ca. 4 kW
Features
- Easy change of the frames with blades.
- Infeed of the products with bottom and side belts, these side belts are adjustable by handwheel.
- Standard with a outfeed plate and side guides to feedthe sliced loaves to the packing line, controlled at the end with photocell.
Optional features
- Top belt to control free baked and round bread.
- Oil spray system for products with high rye content.
- Synchronisation system for a fully automatic line.
- Integrated bag blower in outfeed table.
- Wide version available for products up to 420 mm in length.
- Extended stroke of the frames for higher capacity.
- 2nd slicing frame.
- Inverter to adjust the speed of the frames with the knives
Compatible with
Packaging
Semi-automatic packaging machine for easy bag opening and loading of bread and buns into pre made wicket bags.
Fully automatic packing machine for loading sliced or unsliced bread and buns automatically into pre made wicket bags.
Closing
Conveyor with clipband closing system. 30 bags per minute.
Conveyor with tab lock closing system. 30 bags per minute.
Conveyor with clipband closing system. 60 bags per minute.
Combination
Slicer in combination with bagblower and closing conveyor.
Slicer in combination with bagloader and closing conveyor.
